Vario Roof Locked Limit Switch

High amperage consumers windows pump are switched on with 80ms time delay.

Vario roof locked limit switch.

130 a 230 820 65 10 switch limit switch roof locked left and right front code. Both switches feed a ground signal back. Vario roof locked limit switch right and left. Wired in series location.

Limit switch signals s69 1 s69 2 s69 3 and s69 11 implausible i e vario roof locked limit switch left s69 3 and or right s69 2 actuated whereas vario roof open lowered limit switch s69 11 and vario roof closed limit switch s69 1 not actuated bi273. Both switches feed a ground signal back. On the locks for vario roof front edge actual values. 374 recognized switched contact closed not recognized switched contact open.

This switch will register if the roof has locked itself to the a pillar. Read switch position and sensor values control vario roof hydraulic unit relays to change direction of pump motor rotation a7 5k1 a7 5k2 5 limit switches indicate position of roof components. Vario roof retracted limit switch 0 75 mm2 mqs s69 11. If you cannot get the hardtop to work and the switch indicator light is flashing it may be jammed.

A jammed hardtop can be fixed by following a reset procedure. S69 2 s69 3 wired to rvc pin44 pr org description. When you buy our item you agree to our terms and conditions. Microswitch s69 2 s69 3 switch number.

On vario roof at front left purpose to connect ground signal through to combination control module n10 3 as soon as left rotary tumbler has locked. Vario roof control switch 2308205310 oem please read below. Most of the time the vario roof operation work ok openig and closing but sometime specially in the last few weeks when i try to close the last step closing the small rear windows do not opwrate and the red light of the oper switch stay on but if some one push down the trunk over the lock inmediatly the operation will continue closing the small windows and switching off the oper red light. The vario roof locked limit switch left rotary tumbler is connected in parallel to the vario roof locked limit switch right rotary tumbler.

The sl500 comes with a variety of features such as a retractable hardtop. Left or right vario roof locked limit switch s69 3 or s69 2 is actuated whereas vario ad77 50 p 6000 09a roof open lowered limit switch s69 11 and ad77 50 p 6000 10a. This switch will register if the roof has locked itself to the a pillar.
